Garmin GPSMAP 9012 12" Chartplotter MFD
Garmin SKU 010-02634-00

Garmin GPSMAP 9012 12" Chartplotter MFD

$4,199.00 USD

Shipping at checkout · Manufacturer warranty per product documentation

Available to order

Installment options may be available at checkout through Shop Pay.

Order Now
  • Shipping
  • Warranty
  • Returns

Garmin GPSMAP 9012 12" Chartplotter MFD

Garmin's 12" 4K flagship MFD. Wireless networking, full Garmin ecosystem, sharpest 12" marine display available at any price.

The Garmin GPSMAP 9012 12" Chartplotter MFD is part of the Garmin GPSMAP 9000 lineup, built for helm navigation, sonar, and vessel network integration. 12" 4K UHD IPS — highest resolution available in a 12" marine chartplotter. Wireless MFD networking — no Ethernet cable required to secondary displays. Networking: Garmin Marine Network, NMEA 2000, Ethernet, Wi-Fi, Bluetooth.

Ideal For

Ideal for offshore fishing boats, cruising powerboats, and sailboats that need a primary helm display with chartplotting, sonar, and room to integrate radar, autopilot, and engine data on one network.

At a Glance

  • Display Size: 12" diagonal
  • Resolution: 2560 x 1600 (4K)
  • Display Type: IPS capacitive touchscreen
  • Sonar: CHIRP, SideVü, ClearVü, Panoptix compatible
  • Preloaded Charts: Navionics+ US, Canada, Bahamas
  • Networking: Garmin Marine Network, NMEA 2000, Ethernet, Wi-Fi, Bluetooth
  • Radar Compatible: Yes — full GMR series
  • Autopilot Compatible: Yes — GHP Reactor series
  • Power Input: 10–32V DC, 20W typical
  • Waterproof: IPX7
  • Warranty: 2 Years

Compatibility & Integration

  • Radar Compatible: Yes — full GMR series
  • Autopilot Compatible: Yes — GHP Reactor series
  • Networking: Garmin Marine Network, NMEA 2000, Ethernet, Wi-Fi, Bluetooth

Complete Specifications

  • Display Size: 12" diagonal
  • Resolution: 2560 x 1600 (4K)
  • Display Type: IPS capacitive touchscreen
  • Sonar: CHIRP, SideVü, ClearVü, Panoptix compatible
  • Preloaded Charts: Navionics+ US, Canada, Bahamas
  • Networking: Garmin Marine Network, NMEA 2000, Ethernet, Wi-Fi, Bluetooth
  • Radar Compatible: Yes — full GMR series
  • Autopilot Compatible: Yes — GHP Reactor series
  • Power Input: 10–32V DC, 20W typical
  • Waterproof: IPX7
  • Warranty: 2 Years
  • Dimensions: 14.89" x 9.69" x 3.57" (with bail mount)
  • Weight: 8.3 lbs

Shipping and tax are shown at checkout. Manufacturer warranty terms are included with the product. Contact us with vessel details before ordering.
